Shinegiant 125kW/261kWh Liquid-Cooled Battery Energy Storage Cabinet
Shinegiant 125kW/261kWh Liquid-Cooled Battery Energy Storage Cabinet Shinegiant 125kW/261kWh Liquid-Cooled Battery Energy Storage Cabinet

loading

Shinegiant 125kW/261kWh Liquid-Cooled Battery Energy Storage Cabinet

5 0 Reviews
Share to:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button
The CIES 261 liquid-cooled energy storage integrated cabinet integrates a complete set of core energy storage components, suitable for outdoor scenarios, and features simple and efficient installation. The equipment utilizes liquid-cooled temperature control and is equipped with multi-layered safety and fire protection, ensuring stable operation. It supports parallel expansion of multiple cabinets, enabling peak-valley arbitrage, photovoltaic power absorption, and emergency power supply. Combined with cloud-based intelligent operation and maintenance, it reduces enterprise electricity costs while ensuring stable power supply to the load, making it suitable for various industrial and commercial scenarios such as semiconductors, precision manufacturing, and distributed energy storage.

  • 125kW/261kWh

  • ShineGiant

Availability:
Quantity:
Inquire Add to Basket

CIES 261 Liquid‑Cooled Integrated Energy Storage Cabinet

  • The CIES 261 liquid‑cooled energy storage integrated cabinet incorporates a full suite of core energy‑storage components, purpose‑built for outdoor deployment with simple, time‑saving on‑site installation. Adopting high‑efficiency liquid cooling thermal management and multi‑layer safety & fire‑protection mechanisms, the cabinet delivers reliable and stable long‑term operation.


Supporting multi‑cable parallel expansion, it enables multiple application scenarios including peak‑valley arbitrage, PV power absorption and emergency backup power. Equipped with cloud‑based intelligent O&M, it effectively cuts corporate electricity expenditure while guaranteeing consistent power supply for loads. Ideal for a wide range of industrial and commercial use‑cases: semiconductor facilities, precision manufacturing plants and distributed energy‑storage projects.

125KW_261kWh储能柜海报设计 (1).png

Product specifications and parameters

                                                                                 DC Battery Parameters

Cell Type：

LFP3.2V 314Ah

Operating Voltage Range：

650-949V

Battery Pack Configuration：

1P260S

Rated Voltage：

832V

Rated Current：

157A

Rated Energy：

261.248kWh

Rated power：

125kW

                                                                                 AC side parameters

Rated AC power：

125Kw

Rated grid voltage：

400V

Rated frequency：

50/60Hz

Power factor：

0.99

Maximum AC current：

198A

                                                                                 System Parameters

Cooling Method：

Liquid Cooling

Operating Temperature：

-35~+55℃

Storage Temperature：

-40~+70℃

Relative Humidity：

0~95%

Application Altitude：

4000m, derated at altitudes >2000m

Noise：

<80dB

Corrosion Resistance Rating：

C4

System Dimensions (L×W×H)：

1200*1400*2490mm

Communication Interface：

RS485/Ethernet/CAN

Protection level

IP55

Weight

<3000Kg
